Description
Specifications
| Parameter | Value |
|---|---|
| Distortion | 200Hz – 10kHz：Factory Standard ＜ 1%（94dB SPL, 80mmMRP处） |
| Frequency Response Curve | After compensation, the output sound pressure is 94dB ± 0.1dB（100Hz - 10kHz） |
| Impedance | 4ohm |
| Continuous Maximum Power | 10W |
| Sound Outlet Diameter | Φ20mm |
| Diameter | Φ104mm |
| Height | 100mm |
| Connector | BNC |
| Standard | / |
Specifications
Parameters | |
THD | 200Hz – 10kHz：The Factory Standard Is Less Than 1%（94dB SPL, 80mmMRP） |
Frequency Response | The compensated output sound pressure is 94 dB ± 0.1 dB (100 Hz - 10 kHz) |
Impedance | 4ohm |
| Continuous Maximum Power | 10W |
Sound Outlet Diameter | Φ20mm |
Mouth Ring | Outer Diameter：Φ48mm Height：11mm |
Diameter | Φ104mm |
Height | 100mm |
Weight | 1276g |
| Interface | BNC |
Frequency response
Compensated 94 dB Sound Pressure Frequency Response Curve (25 mm MRP）
Compensated 94 dB Typical Distortion Curve (25 mm MRP)
